Professional WPC PVC window and door profile extrusion machine

  • 1 - 1 Sets
    $150,000.00
  • >=2 Sets
    $145,000.00
Model Number:
bdx
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 75 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Samples:
$30.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Warranty:
1 year
After-sales Service Provided:
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support, Engineers available to service machinery overseas
Place of Origin:
China
Brand Name:
BDX
Voltage:
380v
Application:
Sheet, Profile, Door and window
Weight:
6500kg
Certification:
CE ISO
Screw Design:
Single-screw
Plastic Processed:
PVC
Dimension(L*W*H):
6500*1700*2100mm
Applicable Industries:
Food & Beverage Factory, Construction works , Energy & Mining
Key Selling Points:
Energy saving
Output (kg/h):
150 - 800 kg/h
Screw diameter (mm):
160 mm
Usage:
Door and window profile production
Name:
WPC PVC door and window profile prodution line
Type:
Production Line
Product:
WPC PVC profile
Color:
Customers' Requirement
Raw material:
WPC PVC
Power(W):
90KW
Supply Ability
Supply Ability:
10 Set/Sets per Year
Packaging & Delivery
Packaging Details
Wooden pellet and EPE film covered or according to buyer's requirment
Port
Shanghai
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 75 To be negotiated
Product Description

WPC PVC  .jpgWPC PVC .jpg

Machine description :



This production line is designed according to international latest technology, mixed PVC with plant fibre symmetrically. It adopts high-efficiency conical double-screw extruder with forcible cooling system to extrude and form. The wood plastic panel out from our line has features of green environment protection, damp proof, antisepticise and not distortion, thus suitable for processing method of wood and can be recycled to reuse. It has been widely used in wide door, partition panel, construction template, base plate of container, furnish panel, etc.



Technical parameters



Main Technical Specification

Model



SJSZ80/156

SJSZ92/188

Screw dia.

mm

Φ80/Φ156

Φ92/Φ188

Screw quantity

piece

2

2

Screw speed

r/min

1-38

1-32.9

Main extruder power

KW

55

110

Heating power (approx)

KW

36

45

Extrusion output

kg/h

200-400

300-550



Main Technical Specification of Auxiliary Machine



Model



BF800

BF1000

Max. product width

mm

800

1000

Draw-off height

mm

150

150

Draw-off force

KN

50

50

Draw-off speed

m/min

0-3

0-2.5

Total power of auxiliary machine

KW

35

40

Cooling water consumption

m3/h

9

12

Compressed air pressure

Mpa

0.6

0.6



Machines' pictures

 WPC PVC  .jpgWPC PVC .jpgWPC PVC .jpgWPC PVC .jpgWPC PVC .jpgWPC PVC .jpgWPC PVC .jpg

Company Information


FAQ

 Why choose us:

1.low cost :
all the machine ,we make it ourself to reduce the cost of our customer.
2.Genuine product with excellent quality :
we choose our material very strict,
all the material come to our factory must pass the quality test
substandard goods are returned to the supplier.
3. Engerneers available to serve oversea:

4.quick delivery:
the company provide just in time delivery with its streamlined supply chain
5.cost saving
we take strong attention to every detail in the manufacturing process,
the quality control in our factory is very strict,
all defective semi-manufactures must be treated again or reject.
all the machine must be checked out ,then deivered to our customer.
all about that pushing up the price,
what we want to do is give our customer a good quality product with stable working and long lived.
