Excellent quality PC/PP/PE hollow sheet extrusion line / machine

FOB Reference Price:Get Latest Price
$10,000.00 - $150,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
BDX --PC/PP/PE hollow sheet extrusion line
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Application:
Plates
Plastic Processed:
pp,pc,pe
Screw Design:
Single-screw
Automatic Grade:
Fully Automatic
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
BDX
Voltage:
380V 50HZ 3Phase(Customized)
Dimension(L*W*H):
Machine Model
Weight:
8-20T
Certification:
CE ISO
After-sales Service Provided:
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support, Engineers available to service machinery overseas
Warranty:
2 Years
Name:
PC/PP/PE hollow sheet extrusion line
Raw material:
PC pp pe Granules for sheet extrusion line
Processing Type:
extruding line
Other name:
PC/PP/PE hollow sheet extrusion line
sheet thickness:
2~12mm
Max width:
2200mm for PC/PP/PE hollow sheet extrusion line
Usage:
Making PC/PP/PE hollow sheet
Motor:
Siemens
Contactor:
RKC
Power(W):
150~300kw
Supply Ability
Supply Ability:
50 Set/Sets per Year PC/PP/PE hollow sheet extrusion line
Packaging & Delivery
Packaging Details
standard sea package with cover film , wood pallet or stretch film for hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine
Port
Shanghai Port
Video Description

hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine



 Products sheet shows of hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine

Product Description


About hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine

The hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine is applicable to produce PC,PP,PE hollow profile sheet. The products is used widely for building, decorating, advertisement laying, road noise isolation ,roofing and packing. PP hollow profile board can instead of carton which have feature like light weight, high strengthen, moisture-proof, antisepsis.



Machine part detailed introduction of hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine

 1. The vacuum calibrator featured with wear-resistance, dirty free and the lifting, falling and leveling for the forming plates is much easier to be controlled.

2. High speed screw, low energy consumption with high rotation speed to match gear pump and stable pressure; output capacity is 25% higher than other brand extrusion lines. because of special design of forming plates.



3. Special designed cooling system for all section of forming plates, and unique designed vacuum system for each section of forming plate.

4. Special designed temperature control oven with cross heat shrink forming, which is much easier to be controlled than other brand extrusion lines.

5. The softness of pull rolls could be customized on request to extend its stretch.

6. The air capacity of hollow sheet and low pressure could be adjusted and controlled slightly, which is easily to be controlled than any other brand extrusion lines.

7. Unique T-Die made by JC Times is specially designed for PP hollow sheet. The thickness of hollow sheet could be from 2mm to 10 mm with twin-wall. The ribbed between walls could be rectangular and diagonal shape.

8. Anti-UV co-extrusion layer could be one sided or two sided, outer surfaces could be sandy or glossy according to configuration requirement.High percentage of recycled flakes could be mixed with the virgin materials.



 Reference Parameter of hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine

Extruder model

Φ100

Φ120

Product width

1300/1500mm

2100mm

Product thickness

2-12mm

2-12mm

Motor power

110kw

132kw

Papacity

250-300kg/h

400-450kg/h

















Detailed images of hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine

Main detailed machine parts of hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine

Extruder: special venting type design, advanced PLC temperature control system to ensure that plastic sound and high-yield stability in plastics extrusion.
Screen Changer: optional hydraulic quick changer device, so that the process of changing network quickly and efficiently; duplex and special sealing structure, and ensuring stability for network devices.
Mould: mould made of high-quality alloy steel with high activity of the throttling device, so the distribution of material flow in the die pressure is uniform; the upper and lower lips of die is of differential regulation, ensures a uniform thickness from top to bottom.
Vacuum forming stand: forming system with a fast heat exchange cooling system, and with vacuum system, an effective staggered, sequential distribution to guarantee the accuracy of the sheet’s shape.
Vacuum system consists of two independent sub-structure, each subsystem equipped with a fixed number of three-loop vacuum lines, each carrying a fixed cycle of both the vacuum-conditioning system and vacuum display system, thus making the surface of vacuum plate uniform and stable .

Application of PC/PP/PE hollow sheet

There are some kinds of plastic hollow sheet,such as PC,PP,PE.

PC hollow sheet is widely used as sun proof ceilings of office building, hall, market, stadium, recreation center and public facilities; weather shed of bus station, summer house, and corridor of lounge hall; Safe sun-proof ceilings of airport and factories, velarium of modernized agriculture, livestock breeding industry and indoor swimming pools; noise barrier on high way and elevated road in cities, advertisement billboard, lighting box and exhibition decoration; partition wall between office and living room, and between bathroom and toilet.

PP PE hollow sheet can be processed into turnover case, packaging case, clapboard, lining board, backing board and pallet, etc, due to its advantages of light weight, high tenacity, damp proof, environmental performance and secondary processing. It is widely used in such fields as the electron, household electrical appliances, packaging, machinery, postal, food, medicine, pesticide and advertisement decoration, etc.







Packaging & Shipping

standard wood case ,PE stretch wrapping film and sea-worthy packaging for hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine

50~70 working days for hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine



Our Services

hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine



Company Information



FAQ

hollow sheet extrusion line/hollow sheet line /hollow sheet extrusion machine

1.Will the machine be delivered on time ?
answer: Sure,we will deliver your machine up recieving the balance payment.

 2.How about the machine quality?
answer:our machine quality is reliable.We select every parts ot the machine strictly and production and installation is done by professional workers.We test the each production step for the  best machine.

3.How about the price?
answer:you know ,the goods counts the the price.We select the best machine raw material such as siemens electrics,schneider and ABB etc.We will provide you the best machine with best price.





If you have any needs or questions about our products ,please contact me by the above contact way for the detailed further information!
