pp packing strap making machine/production line

FOB Reference Price:Get Latest Price
$30,000.00 - $80,000.00 / Sets | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 45 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Application:
Packing
Plastic Processed:
PP
Screw Design:
Single-screw
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Sevenstars
Voltage:
380V
Dimension(L*W*H):
40*4*3.5
Weight:
20t
Certification:
CE & ISO9001
After-sales Service Provided:
Field installation, commissioning and training, Online support
Warranty:
1 Year
Raw material:
PP flakes
Inverter:
ABB Brand
Temperature control:
Japan RKC
Strap width:
12/16/18/19mm
Strap thickness:
0.8/0.9/1.0mm
Automatic Grade:
Full
Power(W):
75KW
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
Standard wooden box or stretch cover film
Port
Shanghai port
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 45 To be negotiated
Video Description
Contact Information



Descripition:

This machine is main used to make pp strap ,pp packing strap.

Adopt the plc control the whole line do the auotmatic production.

it use the melting pump and pressure sensor ensure the production stable and strap quality control.

The raw material you can use is 100% recycled pet flakes from the waste pet bottles,or virgin material or mixed with each other.



Advantage:

1.Use 100% Recycled PP Flakes to reduce the cost.

2.Good dehumidifer drying system(Crystallization system optional ) to ensure the material equal dryer to produce high quality strapping.

3.Special design hot forming tensile tank to make good forming ,equal width,straight strap.



Machine parameter:

Model
Capacity
(kg/h )
Strap size
(mm)
Installed Power
(KW)
Manpower
Machine size
(L*W*H m)
SJ65/33 Single strap
50~60
9~19
85
1~2
35*4*5
SJ75/33 Single strap
80~100
9~19
100
1~2
38*4*6
SJ75/33 Double
strap
80~120
9~19
110
1~2
40*4*6
SJ90/33 Double
strap
120~150
9~19
150
1~2
45*5*7
SJ120/33 Double
strap
150~200
9~19
220
1~2
45*5*7
