High quality PE PP PET PVC plastic recycling granulator pelletizer machine price

  • 1 - 1 Sets
    $36,000.00
  • >=2 Sets
    $35,000.00
Model Number:
SJ85 SJ100/33 SJ100/33 & SJ120/10 Others
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 Negotiable
Customization:
Customized packaging (Min. Order: 1 Sets)
Graphic customization (Min. Order: 1 Sets)

More

Customized logo (Min. Order: 1 Sets) Less
Samples:
$10.00 /Sets | 1 Sets (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Applicable Industries:
Building Material Shops
Condition:
New
Type:
Recycling Granulator
Capacity:
100-1000(kg/h)
Place of Origin:
Jiangsu, China
Brand Name:
SEVENSTARS
Material:
PP/PE
Screw Design:
Single
Voltage:
380 50hz
Power:
30-150KW
Dimension(L*W*H):
15m*4m*3.2m
Weight:
8T
Certification:
CE&ISO9001
Warranty:
1 year
After-sales Service Provided:
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support, Video technical support, Engineers available to service machinery overseas
Contactor:
Siemens brand for plastic granulator
Electric Relay:
Siemens brand for plastic granulator
Brand of bearing:
NSK brand for plastic granulator
inverter:
ABB for plastic granulator
Heating mode:
Cast aluminum heating
Cut way:
water-ring or noodle pelletizing
diameter of screw:
85-180(mm) for plastic granulator
color:
at customer's need
material of screw:
38CrMoAl
Packaging & Delivery
Packaging Details
Packing for plastic granulator
1.Wooden case
2.Sea worthy packing
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 To be negotiated
Video Description

Newest high quality PE PP PET PVC  plastic recycling granulator machine price/manufacturer of plastic pelletizer machine



Product description

Plastic film and bags granulating making machine

raw material:PE plastic film

final product: PE granules

output:150-800kg/h

cutting type:water ring



Components included in plastic pelletizing machine :

1.Screw feeder   2. film compacting machine   3. Extruder  4.High speed screen changer and die head  5. water-ring pelletizer  6. dewatering machine  7.vibration screen  8. Air blower   9. Silo



Advantages of this plastic pelletizing machine :



PE/PP recycling granulating machine is special equipment for the PE PP film recycling granulating, it equipped with comacting machine which cound pre- compact the film into smaller granules, then easily feed into screw barrel of extruder, its efficiency is high and can improve production capacity and save labour cost.



it has two vacuum exhuasting mouth on extruder barrel which can fully vent the moisture in the material and hence the final granule quality will be very perfect.



at the end of screw barrel, it equipped with double post fast speed hydraulic non -stop screen changer which can effetively filt out the dirty in the plastic melt.



the pelletizing adopts water flush pelletizing which is easier to operate, and the shape and appearance of granule is good.





 Main parameters of the machine:



Model of PE/PP plasticpelletizing line

SJ85

SJ100

SJ130

SJ160

extruder screw diameter

85

100

130

160

main motor of extruder

55

90

       132

160

main motor of compacting machine

37

55

       75

90

production capacity

100-150

200-300

300-400

500-600

Production Flow

Finished Products

ModelScrew Diameter(mm)Rotary Speed(rpm)Main Motor Power(kw)Compacting Machine Power(kw)Output(kg/h)
SJ85-308510-1205537100-150
SJ100-3010010-1209055200-300
SJ130-3013010-12013275300-400
SJ160-3016010-12016090500-600
SJ180-3018010-120250132



800-1000



Company information

        Zhangjiagang Sevenstars Machinery Co.,Ltd. was founded in 2006. it is an enterprise specialized in producing plastic machinery.it lies to the south of the middle and lower reches of Yangtze River.It is located in the National civilization and hygienic city-zhangjiagang , Surrounded by the economic belt of Suzhou,Wuxi,Changzhou,Nanjing and Shanghai.Both land and river transports are rather convenient.We sell our products to Europe middle,Africa and Asia,etc country and region.Our products enjoy a high reputation home and abroad.







Our services

1.Upon request Supplier will dispatch engineers to install the machines and do commissioning together with customer’s workers.

2.Meanwhile, engineers will teach how to operation, maintain for buyer’s engineers, worker on site.

3.We also offer long term technical guidance.



FAQ

1.How about the quality about this machine?

Answer: yes,my friend,please rest assured,we have nearly 10 years experience for this machine.quality is no problem.



2.How about the output about this machine?is the data real?

Answer: my friend,we have tested that machine many times,then get this data,it is real and can meet your need.



3.Wether you deliver in time?

Answer: sure,once we receive your payment, then delivery immediately.



4.What about your after service?

Answer: we can send our engineers to you factory and offer long term technical guidance.
